PV Connector
Baumuster_geprft_TUV_Nord Baumuster_geprft_TUV_Nord
PV2 TUV Certificate
Pdf DOWNLOAD 		 PV TUV Certificate
Pdf DOWNLOAD


PV-P1_20
PV-J1_20		 Connector System for Photovoltaic

Type / module number PV-P1_20 & PV-J1_20
Size, mm
(L x Ø)		 PV-P1_20, Positive 40.3 x 13.3
PV-J1_20, Negative 42.5 x 13.3
Conformity standards UL 1703 Intend to apply
EN 50521:2008 R 44 780 11 397245
Others IEC61215, IEC 61646, IEC 61730
Rated voltages DC 1000V (TÜV)
Rated currents 20A
Contact resistance ≦ 0.25 mΩ
Wire size range (mm2) 2.5 & 4
Protection degree IP68(1.5m, 24hr)
Overvoltage category III, 8kV
Flammability class UL94-V0
Material Insulation TPE/PA
Contact Cu/Tin plated
Insertion force ≦50N
Withdrawal force ≧50N
Ambient temperature -40~+85℃
Limiting temperature -40~+125℃
Note Do not disconnect under load
pv-p1-20-1
PV-P1_20

pv-j1-20-1
PV-J1_20



Insertion force


PV-P1_35
PV-J1_35		 Connector System for Photovoltaic

Type / module number PV-P1_35 & PV-J1_35
Size, mm
(L x Ø)		 PV-P1_35, Positive 51.0 x 13.6
PV-J1_35, Negative 51.0 x 13.6
Conformity standards UL 1703 Intend to apply
EN 50521:2008 R 44 780 11 397245
Others IEC61215, IEC 61646, IEC 61730
Rated voltages DC 1000V (TÜV)
Rated currents 35A
Contact resistance ≦ 0.25 mΩ
Wire size range (mm2) 4 & 6
Protection degree IP68(1.5m, 24hr)
Overvoltage category III, 8kV
Flammability class UL94-V0
Material Insulation TPE/PA
Contact Cu/Tin plated
Insertion force ≦50N
Withdrawal force ≧50N
Ambient temperature -40~+85℃
Limiting temperature -40~+125℃
Note Do not disconnect under load
pv-p1-35-1
PV-P1_35

pv-j1-35-1
PV-J1_35



Insertion force


PV-P2_20
PV-J2_20		 Connector System for Photovoltaic

Type / module number PV-P2_20 & PV-J2_20
Size, mm
(L x O)		 PV-P2_20, Positive 45.5 x 20.0
PV-J2_20, Negative 45.5 x 20.0
Conformity standards UL 1703 Intend to apply
EN 50521:2008 R 44 780 11 397245
Others IEC61215, IEC 61646, IEC 61730
Rated voltages DC 1000V (TÜV)
Rated currents 20A
Contact resistance ≦ 0.25 mΩ
Wire size range (mm2) 2.5 & 4
Protection degree IP67(to the housing wall)
Overvoltage category III, 8kV
Flammability class UL94-V0
Material Insulation PA
Contact Cu/Tin plated
Insertion force ≦50N
Withdrawal force ≧50N
Ambient temperature -40~+85℃
Limiting temperature -40~+125℃
Note
pv-p2-20-1
PV-P2_20

pv-j2-20-1
PV-J2_20



Insertion force


PV-P2_35
PV-J2_35		 Connector System for Photovoltaic

Type / module number PV-P2_35 & PV-J2_35
Size, mm
(L x O)		 PV-P2_35, Positive 45.5 x 20.0
PV-J2_35, Negative 45.5 x 20.0
Conformity standards UL 1703 Intend to apply
EN 50521:2008 R 44 780 11 397245
Others IEC61215, IEC 61646, IEC 61730
Rated voltages DC 1000V (TÜV)
Rated currents 35A
Contact resistance ≦ 0.25 mΩ
Wire size range (mm2) 4 & 6
Protection degree IP67(to the housing wall)
Overvoltage category III, 8kV
Flammability class UL94-V0
Material Insulation PA
Contact Cu/Tin plated
Insertion force ≦50N
Withdrawal force ≧50N
Ambient temperature -40~+85℃
Limiting temperature -40~+125℃
Note
pv-p2-35-1
PV-P2_35

pv-j2-35-1
PV-J2_35



Insertion force


PV-PJS3
PV-PJB3		 Connector System for Photovoltaic

Type / module number PV-PJS3 & PV-PJB3
Size, mm
(L x O)		 PV-PJS3, Positive 55.5 x 28.5
PV-PJB3, Negative 55.5 x 28.5
Conformity standards UL 1703 Intend to apply
EN 50521:2008 R 44 780 11 397245
Others IEC61215, IEC 61646, IEC 61730
Rated voltages DC 1000V (TÜV)
Rated currents 20A
Contact resistance ≦ 0.25 mΩ
Wire size range (mm2) 2.5 & 4 & 6
Protection degree IP67
Overvoltage category III, 8kV
Flammability class UL94-V0
Material Insulation PA
Contact Cu/Tin plated
Insertion force ≦50N
Withdrawal force ≧50N
Ambient temperature -40~+85℃
Limiting temperature -40~+125℃
Note
pv-pjs3-1
PV-PJS3

pv-pjb3-1
PV-PJB3



Insertion force



Connector System for Photovoltaic

UL Type / module number PV2-P1H_0
PV2-J1H_0		 PV2-P1H_2
PV2H-J1H_2 		 PV2-P1H_4
PV2H-J1H_4
TUV Type / module number PV2-P1H_35
PV2-J1H_35 		 PV2-P1H_25
PV2H-J1H_25
Size, mm
(L x O)		 PV2-P1H, Positive 62.5 x 19.5
PV2-J1H, Negative 64.0 x 19.5
Conformity standards UL 6703 E320476
EN 50521:2008 R 44 780 11 397226
Others IEC61215, IEC 61646, IEC 61730
Rated voltages DC 1000V (TÜV), DC 600 (UL)
Rated currents(TÜV) 35A 25A
Rated currents(UL) 30A 20A 15A
Contact resistance ≦ 0.5 mΩ
Wire size range (AWG/mm2) 10/6.0 12/4.0 14/2.5
Protection degree IP68(1.5m, 24hr)
Overvoltage category III, 8kV
Flammability class UL94-5V/V0
Material Insulation PC/PA 66
Contact Tin plated copper alloy
Ambient temperature -40~+85℃
Limiting temperature -40~+125℃
Note Do not disconnect under load
pv2-p1h-25-1
PV2-P1H

pv2-j1-25-1
PV2-J1H



Insertion force


PV2-P2
PV2-J2		 Connector System for Photovoltaic

UL Type / module number PV2-P2_0
PV2-J2_0		 PV2-P2_2
PV2H-J2_2 		 PV2-P2_4
PV2H-J2_4
TUV Type / module number PV2-P2
PV2-J2
size,mm(L x Ø) PV2-P2, Positive 49.5x19.5
PV2-P2, Nagative 51.0x19.5
Conformify standards UL 6703 E320476
EN 50521: 2008 R 44 780 11 397226
Others IEC61215,IEC61646,IEC61730
Rated voltages DC 1000V (TÜV),DC600V(UL)
Rated currents(TÜV) 35A
Rated currents(UL) 30A 25A 15A
Contact resistance ≦ 0.5 mΩ
Wire size range (AWG/mm2) 10/6.0 12/4.0 14/2.5
Protection degree IP67
Overvoltage category III, 8kV
Flammability class UL94-5V/V0
Material Insulation PC/PA 66
Contact Tin plated copper alloy
Ambient temperature -40~+85℃
Limiting temperature -40~+125℃
Note Do not disconnect under load
pv2-p2-1
PV2-P2

pv2-j2-1
PV2-J2



Insertion force
